Free drivers for D-Link DFE-530TX+. Found 8 files for Windows Vista, Windows Vista 64-bit, Windows XP, Windows XP 64-bit, Windows 2000, Windows 98, Windows ME, Windows 95, Windows NT, other, Mac OS 8x, Mac OS 9x, Mac. Product Registration. Register your product to extend your free support from 30 days to 90 days.

1.install the DFE-530TX+ network adapter in MAC OSX

Step 1 Power down the computer and disconnect the power cable. Print server.

Step 2 Remove the left side panel of the case.

Step 3 Insert the DFE-530TX+ into an available PCI slot and tighten the screw until the DFE-530TX+ is securely in place.

Step 4 Replace the side panel and turn computer on.

Step 5 Insert the DFE-530TX+ installation CD into the CD-ROM drive.

Step 6 Open the CD-ROM icon on the desktop that appears displaying DFE-530TX+ just below the icon.

Step 7 Open the Macintosh folder.

Step 8 Open the DFE-530TX+ driver for MAC OS.

Step 9 Open the installer program.

Step 10 Click on install to complete the installation process.

2.install the DFE-530TX+ network adapter in Linux Red Hat

Note: New Distributions of Linux support this card with built-in drivers and near auto-installation.

Dfe 530tx Driver

Follow these instructions to install the DFE-530TX+ Rev. D1 and D2 in Red Hat 6.x.

The Readme.txt file has excellent instructions for more advanced users in Red Hat 6.x and up.

For novice users, the following step-by-step instructions should suffice, assuming the floppy is mounted.

$ cd floppy
$ cp rtl8139.c /root(or any temp directory)
$ cd /root
$ gcc -DMODULE -D__KERNEL__ -Wall -Wstrict-prototypes -O6 -c rtl8139.c `[ -f /usr/include/linux/modversions.h ] && echo -DMODVERSIONS`

[Enter]

D-link Dfe 530 Tx Driver

$ insmod rtl8139.o

At this point the drivers have been installed and inserted. Configure the network properties of the card according to your current network settings.

For Red Hat 7.0 the install is a little trickier because of a known issue with the default install of the OS.

The workaround is as follows:

First, you must change the following file: /usr/include/linux/modversions.h Using any text editor such as PICO or vi, insert the following line into this file:

#include linux/modsetver.h

Then continue with the compilation and install:

cd floppy
cp rtl8139.c /root(or any temp directory)
cd /root
gcc -I /usr/src/linux/include -DMODULE -D__KERNEL__ -Wall -Wstrict-prototypes -O6 -c rtl8139.c `[ -f /usr/include/linux/modversions.h ] && echo -DMODVERSIONS`

[Enter]

insmod rtl8139.o
